Our product portfolio includes the Aluminium Single Core PVC Insulated Unsheathed Cables, designed to meet the diverse needs of various industries. These cables are known for their high-quality insulation and robust construction, ensuring reliability and performance in a range of applications, from electrical installations to control panels and machinery. Polycrust Wires & Cables offers solutions that combine durability and efficiency, adhering to the highest industry standards.
Product Quality Specifications
- Size: 1.5 Sq.mm to 300 Sq.mm
- Conductor: H 2 Grade Aluminium
- Insulation: Special grade PVC
- Packing: 90mtrs, 100mtrs polywrapped and higher lengths on special order
- Specifications: IS-694, IS-8130, IS-5831
Aluminium Single Core PVC Insulated Cables
| Nominal Area of Conductor (sq.mm) | Thickness of Insulation (Nom.) mm | Approx Overall Diameter (mm) | Resistance (max) per km @ 20°C (Ohms) |
|---|---|---|---|
| 2.5 | 0.8 | 3.95 | 12.10 |
| 4.0 | 0.8 | 4.70 | 1.41 |
| 6.0 | 0.8 | 5.55 | 4.61 |
| 10.0 | 1.0 | 6.90 | 3.08 |
| 16.0 | 1.0 | 8.10 | 1.91 |
| 25.0 | 1.20 | 9.85 | 1.20 |
| 35.0 | 1.20 | 11.30 | 0.868 |
| 50.0 | 1.40 | 12.80 | 0.641 |
Why Choose Us
At Polycrust Wires & Cables, our dedication to innovation in cable manufacturing ensures that you receive products engineered for superior performance, durability, and safety. Our Aluminium Single Core PVC Insulated Cables exemplify this commitment, providing exceptional quality and reliability for a wide range of applications.
